p The files copied to your working directory are shown below Door.cae ABAQUS model database file Door.jnl ABAQUS model database journal file Door.inp ABAQUS input deck Door.odb ABAQUS output database file pbs-abaqus pbs job submission script A sample PBS script for ABAQUS is shown below. Copy the job files to your working directory using the following commands
Å Serious compute loads must be launched via PBS on Tango.
Menu command sequences are linked by ">" symbols. Text inside indicates that there is a button to push in the GUI of the program being described. A schematic of the assembly is shown in the following figure. While a crash event generally lasts for around 100 milliseconds, the time step of the case study has been reduced to 10 milliseconds to reduce the job time. This is analogous to the EURONCAP pole test, in which a car is propelled sideways into a rigid pole of diameter 254 mm at 29 km/h. The case study is a car door being propelled into a pole. Unfortunately we can only offer assistance with Abaqus to people from VPAC member institutions. ë Because Abaqus is commercial software and only licensed for academic use VPAC users email a request to asking to be given access to the package. Please not that model pre-processing is not discussed. C This tutorial demonstrates how to run and view the results of an explicit crash simulation using the ABAQUS suite of FEA products on VPAC's HPC facility.
